MegaFuga D101

• Provides a crack free, smooth appearance.
• Resistant to water, frost and high temperature.
• Prepared and applied easily.

Usage Areas

• MegaFuga is suitable for use on the joints with gaps, ranging between 1 and 6 mm on such floors coated with ceramic, natural stone, granite ceramic and marble and in horizontal and vertical joint gaps in indoors spaces.


  ---

  Technical Informations

  • PerformanceAbrasion resistance ≤ 2000 mm³ TS EN 12808 – 2
    Bending strength after dry storage ≥ 2.5 N/mm² TS EN 12808 – 3
    Bending strength after freezing – thawing cycles ≥ 2.5 N/mm² TS EN 12808 – 3
    Compression strength after dry storage ≥ 15 N/mm² TS EN 12808 – 3
    Compression strength after freezing – thawing cycles ≥ 15 N/mm² TS EN 12808 – 3
    Contraction ≤ 3 mm/m TS EN 12808 – 4
    Water absorption after 30 minutes ≤ 5 gr TS EN 12808 – 5
    Water absorption after 240 minutes ≤ 10 gr TS EN 12808 – 5The foregoing values represent the results of the laboratory tests conducted at 23 ± 2°C temperature and 50% ± 5 relative humidity conditions. The values provided as per the table may vary depending on the surface and ambient conditions.

    Application LimitsUseful time for prepared mortar – Pot life: Maximum 1.5 hours
    Drying time: Minimum 12 hours
    Opening the traffic: 24 – 48 hours

    The foregoing values represent the results of the laboratory tests conducted at 23 ± 2°C temperature and 50% ± 5 relative humidity conditions. The values provided as per the table may vary depending on the surface and ambient conditions.

    Technicial Specificationsa. Chemical Structure: Cement based joint filler with polymer additive
    b. Dry Density: 1.25 ± 0.05 gr/cm³
    c. Mortar Density: 1.90 ± 0.05 gr/cm³
    d. Grain Size: ≤ 150 µm
    e. Color: White, Light Gray
    f. Temperature Resistance: -15°C to +80°C

    Mixing RatioThe product should be mixed with water, weighing equal to 30 – 33 % of the product. (6 – 6.6 liters of water for a 20 kg package)

    PackagingMegaFuga is delivered in
    • Net 5 kg Polyethylene Bags of 72 units provided on a palette of 80×100 cm in dimension (360 kg)
    • Net 20 kg Kraft Bags of 60 units provided on a palette of 80×100 cm in dimension (1200 kg)

    Reference Standardsa. Certifications / Standards
    • TS EN 13888
    b. Ministry of Public Works and Settlement Item No.
    • Ministry of Public Works and Settlement Item No.: 04.013/2

    Quality Certificates
    • TSE/ CG1
    • G

    ---

    Application Procedure

    • Application Surfaces
      Indoors Walls;
      Ceramic
      Natural stone
      Marble
      Granite
      Indoors and Outdoors Floors;
      Ceramic
      Natural stone
      Marble
      GraniteSurface Preparation :
      • The surface coating materials should have been bonded minimum 24 hours in advance.
      • Joint application should not be initiated before the adhesive is completely dehydrated.
      • Coating surface and joint gaps should have been cleaned and cleansed of oil, dirt and dust.
      • The joint gaps should be moisturized in order to maintain the fixed water absorption of vertical and horizontal parts.

      Application Methods :
      • MegaFuga should be filled into joint gaps with a joint trowel through parallel and crosswise movements.
      • The residuary on the mortar’s surface should be scraped with a soft tip joint trowel or a moisturized sponge, and the thin layer of joint, which may have remained on the surface, should be thoroughly cleaned by wiping with a moist sponge after roughly 20 minute standby time, depending on the ambient temperature.
      • Surface smoothening and cleaning should be performed with a dry cloth before MegaFuga dries completely.

      Application Recommendations :
      • The adhesive and the surface behind the coating should be completely dehumidified in order to prevent yellowing in the case of white joints and undulation in the case of colorful joints after the application.
      • The application thickness of the joint filler should be identical for both floor and wall applications.
      • MegaFuga Guard should be used in order for the prevention of the discoloration of the joint fillers used on such frequently cleaned surfaces and floors as kitchen counters and for the same to be lasting.
      • Such cleaning supplies as bleach, hydrochloric acid and lime remover should not be used in order to ensure that the joint fillings are not damaged. The joint gaps should be cleaned with MegaClean.
      • The product should, once mixed, be used before the expiration of its pot life. Any mortar, the pot life of which has expired, should not be used during the application.
      • Any such foreign substance as lime, cement or plaster should not be added to the mortar prepared.
      • Any extra water should not be added to the mixture.
      • The product should not be applied on unsound surfaces. The soundness and the load bearing capacity of old surfaces should be checked prior to adhesion.
      • The surface should be preserved from air currents and water contact during and after the application.
      • The product should not be applied to such surfaces, which are exposed to risk of freezing within the next 24 hours, which are frozen or the frost of which is thawing.
      • Refer to our technical support hotline for recommendation on different surface applications. (PHONE: 444 4 595)

      Surface and Ambient Temperature
      The surface and ambient temperature should be between +5°C and +30°C whilst at application.

      ---

      Color Options
